60KVA Online UPS System - Premium Power Protection for Industrial & Data Center Applications

Brand Name:	Daxin
Model Number:	EX 3C3 60K
MOQ:	1 pc
Packaging Details:	Woodcase/ Paper box
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

Document:

Battery Type:

Lead-acid Or Lithium-ion

Load Capacity:

60KVA/48KW

Input Voltage:

285-475VAC (3Ph+N)

Frequency Range:

50/60Hz ±10%

Transfer Time:

Waveform:

Pure Sine Wave

Battery Configuration:

32-40 Cells (12V Sealed Lead-acid)

Supply Ability:

6000pcs/month

Highlight:

rack mounted high frequency ups

rack mounted ups uninterruptible power supply

Product Description

60KVA Online UPS System - Premium Power Protection for Industrial & Data Center Applications

Key Specifications

Attribute	Value
Battery Type	Lead-acid or lithium-ion
Load capacity	60KVA/48KW
Input Voltage	285-475VAC (3Ph+N)
Frequency Range	50/60Hz ±10%
Transfer Time	0ms
Waveform	Pure Sine Wave
Battery Configuration	32-40 cells (12V sealed lead-acid)

Why Choose This Online UPS Solution?

Military-grade surge protection
IP42-rated enclosure for dust protection
-40°C to +70°C storage range
85% load capacity at 40°C ambient temperature
Compliant with IEC 62040-3 standards for voltage and frequency variation tolerance

Available Configurations

N+1 redundant systems
Extended runtime battery cabinets
Customizable power distribution options

Technical Parameters

Parameter	Specification
UPS Model	EX 3C3 60K
Capacity	60KVA/48KW
Input Voltage	285-475VAC (3Ph+N)
Output Voltage	380/400VAC (3Ph+N) ±1%
Frequency Range	50/60Hz ±10%
Transfer Time	0ms
Waveform	Pure Sine Wave
THD	<2% (linear), <5% (non-linear)
Dimensions (W×D×H)	790×360×1010mm
Weight	85kg

Ideal Applications

Data Centers - Protects servers and network infrastructure
Industrial Automation - Ensures continuous production line operation
Healthcare Facilities - Safeguards critical medical equipment
Broadcast & Telecom - Prevents equipment damage from power anomalies

Key Features

True Online Double Conversion UPS Benefits

Pure sine wave output (THD <2%) guarantees clean power for sensitive equipment
0ms transfer time during power failures ensures uninterrupted operation
Wide input voltage range (285-475VAC) handles severe grid fluctuations
Active PFC (PF >0.99) reduces energy costs and infrastructure requirements

Industrial-Grade Power Protection Features

Advanced overload protection: 150% for 1 minute, 160% for 200ms
Multi-level safeguards: Short-circuit protection, battery overcharge prevention, thermal overload protection
Static bypass switch with 0ms transition for fault conditions

Intelligent Monitoring & Control

Real-time LCD display shows load percentage, input/output voltage, and battery status
Remote management options: RS485 communication, SNMP network monitoring
Optional battery monitoring for cell-level diagnostics

High-Efficiency Performance

94% efficiency in online mode reduces operating costs
93.5% efficiency in battery mode extends runtime
3:1 crest factor supports high inrush current loads
