| Brand Name: | SZDXZH |
| Model Number: | DX-31-H20KL |
| MOQ: | 1 pcs |
| Price: | Negotiable |
| Packaging Details: | Woodcase/ Paper box |
| Payment Terms: | T/T |
| model | 33H10KL | 33H15KL | 33H20KL | 33H30KL | 33H40KL | 33H60KL | ||
| Phase | Three in, three out | |||||||
| capacity | 10KVA/9KW | 15KVA/13.5KW | 20KVA/18KW | 30KVA/27KW | 40KVA/36KW | 60KVA/54KW | ||
| IN | ||||||||
| INPUT VOLTAGE | 3x380/400/415VAC(3PH+N) | |||||||
| Voltage range | 190-520VAC(3 phases) At 50% load；305-478VAC(3 phases) At 100% load | |||||||
| Frequency range | 46-54Hz Or56-64Hz | |||||||
| Power factor | ≥0.99@100% load | |||||||
| OUT | ||||||||
| Output voltage | 3*360VAC/380VAC/400VAC/415VAC (L+N+PE) | |||||||
| Voltage stabilization accuracy (battery mode) | ±1% | |||||||
| Frequency range (synchronous correction range) | 46-54Hz@50Hz；56-64Hz@60Hz； | |||||||
| Frequency range (battery mode) | 50Hz±0.1Hz or 60Hz±0.1Hz | |||||||
| Peak factor | 3:1(MAX) | |||||||
| Harmonic distortion | ≤2% TDH(Linear Load)；≤5% TDH(Nonlinear load) | |||||||
| Overload capacity | Commercial power mode | Commercial power mode: 100%~110%: 60 minutes; 110%~125%: 10 minutes;125%~150%: 1 minutes ;150%: Immediate protection | ||||||
| Battery mode | Battery mode: 100%~110%: 30 seconds; 110%~130%: 10 seconds;125%~150%: 1 minutes ; 150%: Immediate protection | |||||||
| Change time | Municipal electric battery | 0ms | ||||||
| Reverse to bypass | 0ms(Under standard conditions) | |||||||
| Waveform (battery mode) | Pure sine wave | |||||||
| Efficiency | ||||||||
| Commercial power mode | 96% | |||||||
| Battery | ||||||||
| Standard machine(S) | model No | Depends on the application party | ||||||
| quantity | 16-20 (adjustable), default 16 | 32-40 | 32-40 (adjustable), | |||||
| Maximum charging current | 1A-12A(adjustable) | 1A-16A(adjustable) | 1A-18A(adjustable) | |||||
| Charging current | ±13.65V*N±1%(N=8-10) | ±13.65V*N±1%(N=16~20) | ||||||
| Display Description | ||||||||
| LCD display | UPS status, load size, battery capacity, input/output voltage, discharge time, fault indication | |||||||
| physical property | ||||||||
| Long lasting machine | size:D*W*H(MM) | 680*438*133(3U) | 797*438*176(4U) | |||||
| weight KG | 27 | 30 | 30 | 34 | 40 | 45 | ||
| Usage environment | ||||||||
| Temperature and humidity | Relative humidity 0-95% and 0-40 ℃ (non condensing) | |||||||
| noise | Less than 60dB@1 rice | Less than 65dB@1 rice | Less than 70dB@1 rice | |||||
| sup-control | ||||||||
| IntelligenceRS-232/USB | SupportWindows2000/2003/XP/Vista/2008,Windows7/8,Linux and MAC | |||||||
| Optional SNMP card | Power management supports SNMP management and network management | |||||||
| ·If the output voltage is set to 3 x 360VAC and the output power is reduced to 90% (10KL-15KL-20KL) ·When the output voltage is adjusted to 360VA, the capacity is 90% of the rated capacity (30KL-40KL-60KL) ·If UPS is installed or used at an altitude of over 1000m, the output capacity must be reduced by 1% every 100m ·If there are any changes to the current product specifications, no further notice will be given |
|
|||||||
The Standard Machine of our High Frequency UPS weighs just 9.8kg, making it compact and easy to install in any space. But don't let the small size fool you – this Continuous Wave Uninterruptible Power Supply is packed with features to ensure uninterrupted power supply to your equipment.
Our High Frequency UPS is an Online UPS, meaning that it provides consistent power to your equipment by continuously converting AC power to DC power and then back to AC power. This ensures that your devices receive clean, stable power without any interruptions or fluctuations.
The Battery Voltage of our High Frequency UPS is 24V, providing ample backup power to your equipment in case of any power failure. With a wide mains input range of 110 V – 300 V, this High Frequency UPS can handle any voltage fluctuations with ease, ensuring that your equipment remains safe and functional.
Investing in our High Frequency Uninterruptible Power Supply is an investment in the smooth functioning of your business. With its high efficiency, reliable performance, and compact size, our High Frequency UPS is the perfect solution for any commercial or industrial setting.
This High Frequency UPS is a real-time, on-line, and synchronous Uninterruptible Power Supply. It features a built-in isolation transformer (optional) and energy-saving ECO mode. The alarm system alerts users of any issues, and the true online double conversion ensures a 0ms transfer time. The efficiency in battery mode ranges from 0.86 to 0.88, and the output power factor is 0.8.
| Product Category: | High Frequency UPS |
| Advanced UPS System: | True Online Double Conversion (0ms) |
| Efficiency (Commercial power mode): | 0.89 |
| User-Friendly Interface: | Yes |
| Smart Fan Control System: | Yes |
| Alarm System: | Yes |
| Features: | High Efficiency Uninterruptible Power Supply, Synchronous Uninterruptible Power Supply |
| Application Scope: | Widely Used In Various Industries Such As Government, Finance, Communications, Education, Transportation, Meteorology, Radio And Television, Industrial And Commercial Taxation, Medical Care, Energy And Electricity, Etc. |
| Net Weight (Standard Machine): | 9.8kg |
| Packaging Details: | Carton Packaging |
SZDXZH H10KL High Frequency UPS is an advanced UPS system that provides consistent, reliable power supply to various industries such as government, finance, communications, education, transportation, meteorology, radio and television, industrial and commercial taxation, medical care, energy and electricity, etc. With its high frequency uninterruptible power supply, it ensures that your equipment continues to function during power outages, voltage fluctuations, and other power-related issues.
The H10KL model is a synchronous uninterruptible power supply that comes with a smart fan control system and user-friendly interface. It has a switching frequency UPS built-in isolation transformer option and energy-saving ECO mode. This feature allows the system to operate at optimal efficiency while minimizing energy consumption.
Whether you are working in a high-tech laboratory or a manufacturing plant, the SZDXZH H10KL High Frequency UPS is an ideal solution for maintaining power supply. It has a minimum order quantity of 1 and a price of $626.4. The payment terms are T/T and the supply and delivery time are negotiable. The packaging details include carton packaging.
1. Power start button
2. External maintenance bypass switch port
(EMBS interface)
3. USB communication port
4. Emergency power-off function connector
(EPO connector)
5. Uniform flow line port (only applicable to and
Machine mode)
6. Parallel line port (only applicable to parallel)
Machine mode)
7. Smart card slot
8. External battery port (applicable only)
Long extension machine
9. Municipal power input terminal
10. Output terminal
11. Bypass input terminal
12. Input grounding terminal
13. Output grounding terminal
The High Frequency UPS product provides reliable and efficient power protection for critical equipment in various industries. Our technical support team is available to assist with any questions or issues that may arise during installation or operation of the UPS. Our services include:
We also offer customizable service agreements to meet the specific needs of your business. Contact us for more information about our technical support and services for the High Frequency UPS product.
Product Packaging:
Shipping:
Q: What is the brand name of this UPS product?
A: The brand name of this UPS product is SZDXZH.
Q: What is the model number of this UPS product?
A: The model number of this UPS product is H10KL.
Q: Where is this UPS product made?
A: This UPS product is made in China.
Q: What is the minimum order quantity for this UPS product?
A: The minimum order quantity for this UPS product is 1.
Q: What is the price of this UPS product?
A: The price of this UPS product is $626.4.
Q: What are the payment terms for this UPS product?
A: The payment terms for this UPS product are T/T.
Q: What is the supply ability of this UPS product?
A: The supply ability of this UPS product is negotiable.
Q: What is the delivery time for this UPS product?
A: The delivery time for this UPS product is negotiable.
Q: What are the packaging details for this UPS product?
A: The packaging details for this UPS product are carton packaging.
|
