| Brand Name: | SZDXZH |
| Model Number: | DX202 |
| MOQ: | 1 pcs |
| Price: | Negotiable |
| Packaging Details: | Woodcase/ Paper box |
| Payment Terms: | T/T |
Power Range: 1K VA
Working mode: single input and single output, double conversion online operation.
Application scope: Widely used in various industries such as government, finance, communications, education, transportation, meteorology, radio and television, industrial and commercial taxation, medical care, energy and electricity, etc.
Features:
·True online double conversion
·Microprocessor control ensures high reliability
·Input power factor correction
·Output power factor can reach 0.8
·Wide mains input range (110 V – 300 V)
·Efficient frequency conversion mode
·Generator compatible
·Optional exquisite SNMP card can be perfectly monitored alone or with USB, RS232
·Simple operation control through the display, and comprehensive display monitoring UPS status
·ECO mode provides energy saving effect
·Emergency power off (EPO)
·Models above 6K use DSP technology, built-in maintenance bypass switch (optional)
·Smart battery charging design extends battery life and performance
·Built-in isolation transformer (optional)
Technical Parameters
| model | H1K | |
| Phase | Single-phase grounding | |
| capacity | 1000 VA / 800 W | |
| enter | ||
| Voltage range | 110 -300VAC at 50% load | |
| 160 -280 VAC at 100% load | ||
| Frequency range | 40Hz ~ 70Hz | |
| Power Factor | ≧0.99 | |
| Output | ||
| Output voltage | 200/208/220/230/240VAC | |
| Voltage range (battery mode) | ± 1% | |
| Frequency range (synchronous correction range) | 47~53 Hz or 57~63 Hz | |
| Frequency range (battery mode) | 50 Hz ± 0.25 Hz or 60 Hz ± 0.3 Hz | |
| Surge ratio | 3:01 | |
| Harmonic distortion | ≦ 3% THD (Linear Load) | |
| ≦6% THD (non-linear load ) | ||
| Conversion time | AC to DC | 0ms |
| Inverter to Bypass | 4 ms (under standard conditions) | |
| Waveform (Battery Mode) | Pure sine wave | |
| efficiency | ||
| Mains mode | 88% | |
| Battery Mode | 83% | |
| Battery | ||
| Standard Machine | Battery Model | 12V / 9AH |
| quantity | 2 | |
| Maximum charging current | 1.0A (max) | |
| Long-acting machine | Battery Model | Depends on battery configuration |
| quantity | 3 | |
| Maximum charging current | 1A/2A/4A/6A (adjustable) | |
| Appearance | ||
| LCD or LED display | Load size, Battery capacity, AC mode, Battery mode, Bypass mode, Fault indication | |
| Dimensions | ||
| Standard Machine | Dimensions, depth x width x height (mm) | 282 X 145 X 220 |
| Net weight (kg) | 9.8 | |
| Long-lasting models | Dimensions, depth x width x height (mm) | 282 X 145 X 220 |
| Net weight (kg) | 4.1 | |
| Usage Environment | ||
| Temperature and humidity | Relative humidity 20-90% and temperature 0- 40°C (non-condensation) | |
| noise | Less than 50dBA @ 1 meter | |
| Control Management | ||
| Smart RS-232 / USB | 支持 Windows® 2000/2003/XP/Vista/2008, Windows® 7/8, Linux, Unix, and MAC | |
| Optional SNMP | Power management supports SNMP management and network management | |
*When 1-3KVA UPS is set to constant voltage and constant frequency mode, the output power will be reduced by 80%, and when the output voltage of the UPS is set to 208VAC, the output power will be reduced by 80%. When
6/10KVA UPS is set to constant voltage and constant frequency mode, the output power will be reduced by 60%, and when the output voltage of the UPS is set to 208VAC, the output power will be reduced by 90%.
*The above commonly sold models do not support redundant parallel operation.
*200/208/220/230/240VAC is only applicable to long-term machines (200VAC is only applicable to 1-3KVA)
| model | DX202 | DX302 | DX402 | DX502 | DX602 |
| Rated power | 2000W | 3000W | 4000W | 5000W | 6000W |
| Peak power (MS) | 4000VA | 9000VA | 12000VA | 15000VA | 18000VA |
| Battery input | |||||
| Nominal voltage | 12V/24DC | 24V/48VDC | 24V/48VDC | 48VDC | 48VDC |
| Charging current | 0-30A | ||||
| Charging voltage | 13.8VDC for 12V(*2 for 24V;4 for 48VDC;8for 96V | ||||
| Battery High voltage alarm | 15VDC for 12V(*2 for 24V;4 for 48VDC;8for 96V | ||||
| Low voltage alarm of battery | 10.5VDC for 12V(*2 for 24V;4 for 48VDC;8for 96V | ||||
| Battery type | Lithium battery/gel (customized) | ||||
| Communication input | |||||
| Voltage | L N+PE 110V/120V;220V/230V/240V | ||||
| Voltage range | 75-135VAC for 110V;145-265VAC for 220V | ||||
| frequency | 50/60HZ adaptive | ||||
| Communication output | |||||
| Voltage | L N+PE 110V/120V;220V/230V/240V(Can be set) | ||||
| frequency | 50/60HZ±1%(Can be set) | ||||
| Surge power | 4000VA | 9000VA | 12000VA | 15000VA | 18000VA |
| Efficiency | 89% | 90% | 90% | 90% | 90% |
| conversion time | ≤8ms | ||||
| Output waveform | Pure sine wave | ||||
| protection | |||||
| Display | Forced air cooling | ||||
| heat dissipation method | Overvoltage protection, undervoltage protection, overload protection, surge protection, over temperature protection, short circuit protection, etc | ||||
| display | LCD+LED | ||||
| communication (optional) | RS232/RS485/APP/WIFI | ||||
| Working mode | |||||
| Priority given to mains electricity | Prioritize the use of State Grid power supply, and automatically switch to inverter (battery) mode during power outages | ||||
| Power saving mode | Automatically switch to sleep mode when no load is detected in the inverter state | ||||
| Priority given to photovoltaics | Prioritize the use of photovoltaic power generation, with complementary batteries and the power grid | ||||
| Photovoltaic input | |||||
| Maximum photovoltaic input | 12V:18-150VDC | 24V:36-150VDC | 48V:60-150VDC | ||
| Maximum charging current | MPPT 60A | ||||
| Maximum photovoltaic power | For 12V:System:750W | For 12V:System:1500W | For 12V:System:3200W | ||
| Best MPPT | For 12V:System:18-50V | For 12V:System:36-80V | For 12V:System:72-110V | ||
| Maximum working voltage | For 12V:155VDC | For 24V:155VDC | For 48V:155VDC | ||
| Open circuit | |||||
| voltage environment | 0%~95% No condensation | ||||
| relative humidity | “-10℃~40℃ | ||||
| working temperature | ”-15℃~60℃ | ||||
| Storage temperature | |||||
| Packaging size (D * W * H) mm | 630*450*290 | ||||
| Weight (kg) | 20kg | 23kg | 28kg | 32kg | 35kg |
——UPS power solution service provider——
|
