| Brand Name: | Daxin |
| Model Number: | EX 3C3 10K |
| MOQ: | 1 pc |
| Packaging Details: | Woodcase/ Paper box |
| Payment Terms: | T/T |
> Pure sine wave output with voltage stabilization, noise filtering, and frequency synchronization.
> Immune to grid fluctuations, ensuring uninterrupted power for critical IT/industrial loads.
> Enhances system stability and operational efficiency.
> CPU-controlled charging adjusts current based on battery capacity, prolonging battery life.
> Built-in input/output harmonic filters minimize grid pollution and protect co-located equipment.
> Maintains PF ≥ 0.99 under full load, reducing energy waste.
> Minimizes battery usage in unstable grid conditions.
> High-speed frequency synchronization reduces generator sizing requirements (only 2x UPS input power needed).
> Enables UPS activation without grid power for emergency scenarios.
> Output overload/short-circuit protection
> Inverter over-temperature protection
> Battery under-voltage warning & overcharge prevention
> Seamless transition to mains power during maintenance or faults.
> Real-time status updates and parameter tracking.
> Compatible with Windows®, Linux, and macOS.
> Detects individual cell faults (over/under-voltage, imbalance) with alerts displayed on-screen.
LCD Display:
> Conformal coating ("3-proof" protection) for resistance to dust, humidity, and corrosive elements.
| Parameter | Specification |
|---|---|
| Model | EX 3C3 10K |
| Capacity | 10KVA / 8KW |
| Input | |
| - Voltage Range | 110–300VAC (L-N) ±3% |
| - Frequency Range | 46–54Hz (50Hz) / 56–64Hz (60Hz) |
| - Phase | 3-Phase + Ground |
| - Power Factor | ≥0.99 @ 100% load |
| Output | |
| - Voltage | 360/380/400/415VAC (3Ph+N) ±1% |
| - Frequency (Sync) | Matches input in AC mode; 50/60Hz ±0.1% in battery mode |
| - THD | ≤2% (linear load) / ≤5% (non-linear) |
| - Overload Capacity | 110%: 10min (AC) / 30s (Battery) |
| Battery | |
| - Standard | 16x 12V/9Ah (90% charge in 9h) |
| - Extended Runtime | Configurable (16–20 cells) |
| Efficiency | >90.5% (AC) / >87% (Battery) |
| Physical | 592×250×576mm (D×W×H), 38kg |
| Noise Level | <60dB @ 1m |
Ensure seamless power continuity with a UPS designed for precision, durability, and smart management.
(Contact us for custom configurations or extended battery solutions.)
The High Frequency UPS product offers technical support and services to ensure reliable and efficient performance. Our team of experts offer remote monitoring and diagnostic services to detect and resolve any issues quickly.
Additionally, we provide training and consulting services to help optimize your system’s performance and ensure that it meets your specific needs.
With our comprehensive technical support and services, you can have peace of mind knowing that your High Frequency UPS product is always working at its best.
Product Packaging for High Frequency UPS:
Shipping Information:
Our Factory-production lines:
Video
Video
|
| Brand Name: | Daxin |
| Model Number: | EX 3C3 10K |
| MOQ: | 1 pc |
| Packaging Details: | Woodcase/ Paper box |
| Payment Terms: | T/T |
> Pure sine wave output with voltage stabilization, noise filtering, and frequency synchronization.
> Immune to grid fluctuations, ensuring uninterrupted power for critical IT/industrial loads.
> Enhances system stability and operational efficiency.
> CPU-controlled charging adjusts current based on battery capacity, prolonging battery life.
> Built-in input/output harmonic filters minimize grid pollution and protect co-located equipment.
> Maintains PF ≥ 0.99 under full load, reducing energy waste.
> Minimizes battery usage in unstable grid conditions.
> High-speed frequency synchronization reduces generator sizing requirements (only 2x UPS input power needed).
> Enables UPS activation without grid power for emergency scenarios.
> Output overload/short-circuit protection
> Inverter over-temperature protection
> Battery under-voltage warning & overcharge prevention
> Seamless transition to mains power during maintenance or faults.
> Real-time status updates and parameter tracking.
> Compatible with Windows®, Linux, and macOS.
> Detects individual cell faults (over/under-voltage, imbalance) with alerts displayed on-screen.
LCD Display:
> Conformal coating ("3-proof" protection) for resistance to dust, humidity, and corrosive elements.
| Parameter | Specification |
|---|---|
| Model | EX 3C3 10K |
| Capacity | 10KVA / 8KW |
| Input | |
| - Voltage Range | 110–300VAC (L-N) ±3% |
| - Frequency Range | 46–54Hz (50Hz) / 56–64Hz (60Hz) |
| - Phase | 3-Phase + Ground |
| - Power Factor | ≥0.99 @ 100% load |
| Output | |
| - Voltage | 360/380/400/415VAC (3Ph+N) ±1% |
| - Frequency (Sync) | Matches input in AC mode; 50/60Hz ±0.1% in battery mode |
| - THD | ≤2% (linear load) / ≤5% (non-linear) |
| - Overload Capacity | 110%: 10min (AC) / 30s (Battery) |
| Battery | |
| - Standard | 16x 12V/9Ah (90% charge in 9h) |
| - Extended Runtime | Configurable (16–20 cells) |
| Efficiency | >90.5% (AC) / >87% (Battery) |
| Physical | 592×250×576mm (D×W×H), 38kg |
| Noise Level | <60dB @ 1m |
Ensure seamless power continuity with a UPS designed for precision, durability, and smart management.
(Contact us for custom configurations or extended battery solutions.)
The High Frequency UPS product offers technical support and services to ensure reliable and efficient performance. Our team of experts offer remote monitoring and diagnostic services to detect and resolve any issues quickly.
Additionally, we provide training and consulting services to help optimize your system’s performance and ensure that it meets your specific needs.
With our comprehensive technical support and services, you can have peace of mind knowing that your High Frequency UPS product is always working at its best.
Product Packaging for High Frequency UPS:
Shipping Information:
Our Factory-production lines:
Video
Video
