| Brand Name: | Daxin |
| Model Number: | EX 3C3 40K |
| MOQ: | 1 pc |
| Packaging Details: | Woodcase/ Paper box |
| Payment Terms: | T/T |
0ms Transfer Time 40KVA High Frequency Online UPS Enterprise-Grade Power Protection
| Parameter | Specification |
|---|---|
| Model | EX 3C3 40K |
| Capacity | 40KVA / 32KW |
| Input Characteristics | |
| - Voltage Range | 285–475VAC (3Ph+N) |
| - Frequency Tolerance | 50/60Hz ±10% |
| Output Performance | |
| - Voltage Stability | ±1% (steady state) |
| - THD | <2% (linear load) |
| - Overload Capacity | 150% for 1min |
| Efficiency | 94.5% (online) |
| Battery System | 36–40 cells (configurable) |
| Physical | 815×300×1000mm (66kg) |
Engineered for Extreme Reliability:
Available in:
Compliant with IEC 62040-3 Class 1 standards for voltage/frequency variation.
Support and Services:
The High Frequency UPS product is designed to provide reliable and efficient power protection for critical equipment. Our technical support team is available to assist with any product inquiries or issues that may arise. Our services include:
We are committed to ensuring the uptime and performance of your critical equipment, and our technical support and services are designed to help you achieve that goal.
Video
Video
|
