Brand Name: | Daxin |
Model Number: | EX 3C3 40K |
MOQ: | 1 pc |
Packaging Details: | Woodcase/ Paper box |
Payment Terms: | T/T |
External battery connector | Yes |
Smart slot | Yes |
Load capacity | 40KVA / 32KW |
Input Voltage | 285–475VAC (3Ph+N) |
Transfer time | 0 ms |
Battery System | 36–40 cells (configurable) |
Model | EX 3C3 40K |
Capacity | 40KVA / 32KW |
Input Characteristics | |
Voltage Range | 285-475VAC (3Ph+N) |
Frequency Tolerance | 50/60Hz ±10% |
Output Performance | |
Voltage Stability | ±1% (steady state) |
THD | <2% (linear load) |
Overload Capacity | 150% for 1min |
Efficiency | 94.5% (online) |
Battery System | 36-40 cells (configurable) |
Physical Dimensions | 815×300×1000mm (66kg) |
Our technical support team is available to assist with any product inquiries or issues that may arise. Our services include:
![]() |
