Outdoor UPS Power Cabinet – Compact 500VA Wall-Mounted Solution With Remote Monitor

Brand Name:	Daxin
Model Number:	ODC-705835500-12V
MOQ:	1 Set
Packaging Details:	Woodcase/ Paper box
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

Document:

Install Method:

Pole/Wall Mount

Material:

Galvanized Steel/ Stainless Steel

Customized Service:

UPS Capacity:

500VA/400W

DC Input:

Supply Ability:

8000pcs/month

Highlight:

Remote Monitor Outdoor UPS Power Cabinet

Outdoor UPS Power Cabinet

Wall Mounted Outdoor UPS Power Cabinet

Product Description

Outdoor UPS Power Cabinet – Compact 500VA Wall-Mounted Solution With Remote Monitor

Install Method	Pole/Wall Mount
Material	Galvanized steel/Stainless steel
Customized service	Yes
UPS capacity	500VA/400W
DC Input	12V

Outdoor UPS Cabinet - Robust 24V DC Power Backup System Best For Traffic Control

Product Overview

The AAM500-12V Outdoor UPS Power Cabinet is a rugged, compact uninterruptible power supply system designed for remote telecommunications, surveillance systems, and IoT applications. This 12V DC input system delivers 500VA/400W of pure sine wave AC output, ensuring seamless power continuity for sensitive equipment in harsh outdoor environments. Ideal for remote telecom sites & small-scale power backup.

Key Features

500VA/400W output with 220V AC pure sine wave
12V DC input compatible with lead-acid/LiFePO4 batteries
Dual-conversion online UPS with 0ms transfer time
Wide AC input range (172-268V AC) and 0.98 power factor
IP54 (outdoor)/IP20 (indoor) protection

Technical Specifications

Output THD	≤3% (linear), ≤8% (nonlinear)
Overload Capacity	130% for 20s
Charging Current	5-7A
Protections	Input/output OVP/UVP, short-circuit, over-temperature
Dimensions	(W×H×D) 300×450×150mm
Weight	12kg (without batteries)

Monitoring & Control

Local interface:

LED status indicators
Audible alarms

Remote monitoring options:

Standard RS232 port
Optional RS485/SNMP cards
Dry contact alarms (configurable)

Compliance & Certifications

Safety: CE, RoHS
EMC: EN55022 Class A
Environmental: IEC 60068-2 (shock/vibration)

Applications

Remote telecom base stations
Traffic monitoring systems
Solar-powered installations
Security camera networks
