Commercial-Grade All-in-One Solar Storage System – 50kVA / 100kWh PV Battery Energy Solution

Brand Name:	Daxin
Model Number:	DX-BESS-50K130
MOQ:	1 Set
Packaging Details:	Woodcase/ Paper box
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

Document:

Monitoring And Control:

Remote Monitoring And Control Capabilities

Cabinet Lock:

Anti-theft Three Point Lock

Embedded Power Supply:

Brand: Emerson

Protection Level:

Power Output:

Varies Depending On Customer Needs

Cabinet Material:

Galvanized Steel

Supply Ability:

6000pcs/month

Highlight:

All-in-One Solar Storage System

50kVA PV Battery Energy Solution

100kWh PV Battery Energy Solution

Product Description

Commercial-Grade All-in-One Solar Storage System – 50kVA / 100kWh PV Battery Energy Solution

Product Overview

The DX-BESS-50K130 is an advanced solar PV battery solution from DX ENERGY, featuring high-voltage lithium iron phosphate (LiFePO4) battery technology. Designed for large-scale renewable energy storage and backup power applications, this system offers reliability, efficiency, and safety.

Key Attributes

Monitoring And Control	Remote monitoring and control capabilities
Cabinet Lock	Anti-theft Three Point Lock
Embedded Power Supply	Brand: Emerson
Protection Level	IP55
Power Output	Varies depending on customer needs
Cabinet Material	Galvanized steel

System Specifications

Model: DX-BESS-50K130

Nominal Output Power: 50000W

AC Output: 50/60Hz; 3L/N/PE 220/380, 230/400Vac

Grid Type: Three phase

Energy Configuration: 133.12kWh

Dimensions: 1400x1000x1650mm (without inverter)

Weight: ~1500kg

Battery Chemistry: LiFePO4

Certifications: UN38.3, IEC62619, CE, CEI 0-21, VDE-AR-N 4105, IEC 62109

Warranty: 10 years

Inverter Technical Specifications

Max Parallel Sets: 10

Max PV Input Power: 65000W

MPPT Voltage Range: 150-850Vdc

Number of MPPT: 4

Operating Temperature: -40°C to 60°C

Max Efficiency: 97.6%

Battery Technical Specifications

Nominal Voltage: 665.6V

Capacity: 200Ah

Energy: 133.12kWh

Cycle Life: ≥6500 cycles

Operating Temperature: Charge: 0°C to 55°C / Discharge: -20°C to 55°C

System Advantages

Intelligent Temperature Control: Built-in air conditioner maintains battery temperature below 40°C for optimal performance and lifespan.
Reliable: Positive Balance Intelligent BMS provides comprehensive protection, extending battery cycle life.
Flexible: Integrated EMS and BMS technology with AC/DC power supply redundancy and black start function.
Safe: Uses Prismatic Lithium Iron Phosphate (LFP) Battery with aerosol fire extinguishing solution.

Applications

Renewable Energy Storage: Efficient storage for solar PV system energy
Backup Power: Continuous power supply for commercial and industrial facilities

Key Features

Modular Design: 13 battery modules of 10.24KWH connected in series for 133.12kWh total capacity
Eco-friendly: Cobalt-free, non-toxic LiFePO4 chemistry with IP55 enclosure
High Compatibility: 50kW hybrid inverter supports both on-grid and off-grid applications with 4 MPPTs

Tags:

The DC48V photovoltaic/grid-connected outdoor power system is used for outdoor communication power supply and energy storage equipment. Customization is available.
