5KW 5G power supply/microsite power supply/pole mounted power supply/outdoor power supply/pole mounted power supply

Brand Name:	daxin
Model Number:	DX-C-1k20AH
MOQ:	10
Packaging Details:	Wooden pallet+cardboard box

Detail Information

Product Description

Detail Information

Place of Origin:

shenzhen

Certification:

CE,UL

Document:

Color:

Ral7035 Or Ral7032

Type:

Distribution Box,battery/ Meter Box,Outdoor

Protection Level:

Material:

Cold-roll Steel/Stainless Steel

External Size:

600*800*450mm

Application:

Electric Power System

Supply Ability:

10000pcs/month

Product Description

5KW 5G Power Supply - Microsite/Pole Mounted/Outdoor Power Supply

Product Specifications

Attribute	Value
Color	RAL7035 or RAL7032
Type	Distribution Box, Battery/Meter Box, Outdoor
Protection Level	IP55
Material	Cold-Roll Steel/Stainless Steel
External Size	600×800×450mm
Application	Electric Power System

Technical Specifications

Environmental Conditions

Operating Temperature: -40℃ to +55℃
Storage Temperature: -40℃ to +65℃
Operating Relative Humidity: ≤90% (at 40±2℃)
Storage Relative Humidity: ≤95% (at 40±2℃)

Vibration & Seismic Resistance

Withstands sine wave vibration (10-55Hz, 0.35mm amplitude)
Meets YD 5096-2016 seismic performance standards for communication power equipment

Physical Specifications

Dimensions: 300mm (W) × 400mm (D) × 68mm (H)

Interface Configuration

From left to right: AC Input, Battery Connector, DC Load 3, DC Load 2, DC Load 1, Communication Port, Antenna Connector, Ventilation Valve

Indicator Lights

From left to right: Green (Running), Yellow (Warning), Red (Fault)

Mounting Options

Installation: Derrick and flat installation (80mm × 80mm)

Flag mounted (80mm × 80mm)

Product Overview

Electrical Specifications

Input Voltage Range

AC 220V (176V-264V range)
Derated to 1000W output at 100Vac-175Vac
DC 240V/336V (260V-400V range)
Derated to 1000W output at 140Vdc-240Vdc

AC Input Requirements

Rated frequency: 50Hz (±2.5Hz fluctuation)

Power Factor

Load Factor	Power Factor
100%	>0.99
50%	>0.98
20%	>0.94

Input Voltage Characteristics

Input voltage waveform distortion rate ≤5%
No-load losses <1% of rated power (20W)

Output Voltage

Nominal value: -48V (43V-57V range)
Voltage stabilization accuracy: ±0.5%

Efficiency

Load Factor	Efficiency
100%	≥95.5%
50%	≥96%
20%	≥93.5%
