| Brand Name: | Daxin |
| Model Number: | 48V150AHLiBa |
| MOQ: | 1 Set |
| Payment Terms: | T/T |
| Capacity | 150AH/ 7200wh |
| Max. Charge Current | 75A |
| Peak Current | 300A |
| Dimension | L760*W480*H175(mm) |
| Weight | 60Kg |
| Communication | CAN/RS485 |
The 150AH Lithium Iron Phosphate battery is designed for efficient and reliable energy storage. Built with high-quality materials, this rack-mounted battery provides long-lasting power for various applications.
| No. | Item | Parameters |
|---|---|---|
| 1 | Rated Capacity | 150AH |
| 2 | Rated Voltage | DC48 |
| 3 | Rated Energy | 7200wh |
| 4 | Operating Voltage | 37.5V~54.75V |
| 5 | Max.Charge Current | 75A |
| 6 | Max.Discharge Current | 100A |
| 7 | Peak Current | 300A |
| 8 | IP Grade | IP20 |
| 9 | Discharge Temp | -10℃~55℃ |
| 10 | Charge Temp | 0℃~55℃ |
| 11 | Internal Resistance | ≤30mΩ |
| 12 | Cycle Life | 6000 |
| 13 | Communication | CAN/RS485 |
